At Stahl-Becker you can order tinplates in production batches as well as single plates. High quality in every quantity.

Material Material Number DIN Material Code
TS275 1.0375 T57
Material Standard

DIN EN 10202

Dimension standard

DIN EN 10202

Products

Sheets

Dimensions

Sheets 533 x 765 mm:

Thickness (mm) Width (mm) Length (mm)
0,20 533 765
0,32 533 765
0,40 533 765



Sheets 530 x 760 mm:

Thickness (mm) Width (mm) Length (mm)
0,52 530 760
0,60 530 760
Tensile strength (Rm)

340-395 N/mm²

Surface

BK (bright), LG (slightly coldrolled)

Coating electrolytically tinned, shining finish, up to 0,58 mm Thickness E 11,2/11,2 (the thickness of the tin layer is 11,2 g per m²), over 0,58 mm E 14,0
